Introduction of Anti-static Blended Filter Fabric
Polyester anti-static polyester needle felt is based on the appropriate placement in the fabric or yarn in the fiber surface conductive layer of conductive fibers mixed in proper proportion. so that the semiconductor cloth, eliminating the surface of the electrostat ic bag to prevent fires caused by spark s due to static electricity or explosion.
Feature of Anti-static Blended Filter Fabric
The advantages are good conductivity, good air permeability, high efficient dust
collection,easy separation, stable chemical property, good abrasion, long working Iife etc.
Application of Anti-static Blended Filter Fabric
It is widely in high concentration working conditions, eg. Cement, grain, wood processing, textile plant etc
TECHNICAL DATA( Anti-static Blended Filter Fabric) |
Material | PET/anti-static scrim | PET/Conductive fiber/long fiber scrim |
Weight.g/m2 | 500 | 500 |
Thickness:mm | 1.6 | 1.8 |
Air permeability:L/㎡.s | 200 | 200 |
Breaking strength N/5×20cm | warp | ＞800 | ＞1000 |
weft | ＞1300 | ＞1300 |
Breaking elongation% | warp | ＜25 | ＜35 |
weft | ＜55 | ＜55 |
Continuous working temperature ℃ | ≤130 | ≤130 |
Instant working temperature ℃ | 150 | 150 |
Acid resistance | Excellent | excellent |
Alkali resistance | Good | good |
Abrasive resistance | Excellent | excellent |
Finish treatment | Singeing/pressure/light heat setting/Teflon/coating | singeing/pressure/ setting/Teflon/coating |
